Which unit is used to measure electric current?
Ohm
Volt
Watt
Ampere
Electric current is measured in amperes, often shortened to 'amps', which quantify the flow of electric charge per second. One ampere equals one coulomb of charge passing through a point in a circuit each second. The ampere is one of the seven base SI units. Learn more about amperes.
In conventional current flow, electrons are assumed to move from:
Positive to negative
Negative to positive
High voltage to ground
Low voltage to ground
Conventional current flow is defined as the movement of positive charge from the positive terminal to the negative terminal of a source. Although electrons actually move from negative to positive, current is modeled as flowing from positive to negative. This convention was established before the discovery of the electron. Learn more about current flow conventions.
Which material is considered an electrical conductor?
Glass
Rubber
Copper
Wood
Conductors are materials that allow free movement of electrons; metals like copper have low resistance and high conductivity. Copper is widely used in electrical wiring due to its excellent conductive properties and ductility. Insulators like rubber, glass, and wood restrict electron flow and are used to protect against unwanted current paths. Read more about electrical conductors.
What device is used to measure voltage across two points in a circuit?
Ammeter
Voltmeter
Ohmmeter
Wattmeter
A voltmeter is connected in parallel across two points in a circuit to measure the electrical potential difference (voltage) between them. It has a high internal resistance to minimize current draw and avoid affecting the circuit operation. Ammeters, by contrast, measure current and are placed in series. More on voltmeter usage.
Which description matches the schematic symbol for a battery?
A triangle pointing to a line
A circle with terminals
A pair of parallel lines of unequal length
A series of zigzag lines
In circuit diagrams, a battery is represented by multiple pairs of parallel lines where each pair has one long line (positive terminal) and one short line (negative terminal). The length difference indicates polarity. A single pair denotes a cell, while multiple pairs indicate a battery. See common circuit symbols.
Which formula represents Ohm's Law?
E = I × R
I = E × R
E = I + R
R = E + I
Ohm's Law states that the voltage across a conductor (E) is equal to the current through it (I) times its resistance (R). This relationship is expressed as E = I × R. It is fundamental for calculating circuit parameters and analyzing both simple and complex circuits. Read more about Ohm's Law.
What is the SI unit for electrical resistance?
Volt
Ohm
Watt
Ampere
The unit of electrical resistance is the ohm, symbolized by the Greek letter ?. It quantifies how much a resistor opposes the flow of electric current. One ohm is defined as the resistance between two points of a conductor when a constant potential difference of one volt produces a current of one ampere. Learn more about the ohm.
What happens to the total resistance when resistors are added in series?
Total resistance is the reciprocal of the sum
Total resistance remains the same
Total resistance is the sum of individual resistances
Total resistance decreases
In a series circuit, the current flows through each resistor sequentially, and their resistances add together, increasing the total opposition to current. The total resistance R_total = R1 + R2 + ... + Rn. This makes series circuits useful when a specific total resistance is needed. Series resistor calculations.
How does connecting resistors in parallel affect the total resistance?
Total resistance decreases
Total resistance equals average of values
Total resistance remains the same
Total resistance increases
In a parallel circuit, each resistor provides an alternate path for current, reducing the overall resistance. The total resistance is given by the reciprocal of the sum of reciprocals: 1/R_total = 1/R1 + 1/R2 + ... + 1/Rn. This makes parallel circuits advantageous for reducing net resistance. Parallel resistor explanation.
Which instrument is used to measure the current flowing through a circuit element?
Wattmeter
Voltmeter
Ohmmeter
Ammeter
An ammeter is connected in series with a circuit element to measure the current flowing through it directly. It has a very low internal resistance to minimize its impact on the circuit. Voltmeters, in contrast, measure potential difference and are connected in parallel. More on ammeter usage.
What is the total resistance of a 4? resistor and a 6? resistor connected in series?
10?
24?
0.67?
2?
In a series connection, resistances add directly, so the total resistance equals R1 + R2. Here, 4? + 6? equals 10?. This principle applies to any number of series resistors. Series circuit theory.
What is the equivalent resistance of a 4? resistor and a 6? resistor connected in parallel?
2.4?
0.67?
9.6?
10?
For parallel resistors, the total resistance is found using 1/R_total = 1/R1 + 1/R2. Here, 1/4 + 1/6 yields 5/12, so R_total = 12/5 = 2.4?. Parallel connections always result in a lower resistance than the smallest branch. Parallel resistor calculations.
How much current flows through a 4? resistor connected to a 12V battery?
0.5 A
3 A
48 A
0.33 A
Ohm's Law (I = E/R) determines current: 12 volts divided by 4 ohms equals 3 amperes. This basic formula is essential for analyzing DC circuits. Ohm's Law details.
What is the power dissipated by a 5? resistor carrying a current of 2A?
10 W
20 W
0.4 W
2.5 W
Power in a resistor is P = I^2 × R. Substituting I = 2A and R = 5? gives P = (2^2) × 5 = 20 watts. Understanding power dissipation is key for component ratings. Electrical power concepts.
According to Kirchhoff's Voltage Law, the algebraic sum of all voltages around a closed circuit loop is:
Equal to total resistance
Twice the supply voltage
Equal to total current
Equal to zero
Kirchhoff's Voltage Law (KVL) states that the sum of all electrical potential differences around any closed loop is zero. This reflects the conservation of energy in electrical circuits. KVL is indispensable for analyzing complex circuits. KVL explained.
Kirchhoff's Current Law defines that the total current entering a junction equals:
Total current leaving the junction
Total voltage leaving the junction
Zero
Total resistance of the junction
Kirchhoff's Current Law (KCL) asserts that the sum of currents entering any node (junction) in a circuit equals the sum of currents leaving that node. This is based on charge conservation. KCL is crucial for nodal circuit analysis. Learn more about KCL.
In a voltage divider with R1 = 2k? and R2 = 3k? supplied by 10V, what is the voltage across R2?
6 V
4 V
10 V
2 V
A voltage divider divides supply voltage according to resistor ratios: V_R2 = V_S × (R2/(R1+R2)). Substituting values gives 10V × (3000/(2000+3000)) = 6V. Voltage dividers are common for generating reference voltages. Voltage divider formula.
What term describes a connection with negligible resistance that bypasses part of a circuit?
Open circuit
Parallel circuit
Short circuit
Series circuit
A short circuit provides a path of negligible or zero resistance, allowing large currents to bypass portions of the circuit. It can cause circuit damage or fire if not protected. Contrastingly, an open circuit has infinite resistance, preventing current flow. Short circuit definition.
Which condition prevents current flow by having very high or infinite resistance in a circuit path?
Parallel circuit
Short circuit
Open circuit
Series circuit
An open circuit occurs when a path in the circuit has broken continuity or extremely high resistance, stopping current flow. It is the opposite of a short circuit. Open circuits are used for switches controlling current flow. Open circuit meaning.
A 9V battery is connected to a 30? resistor for 2 minutes. How much energy is dissipated in the resistor?
54 J
324 J
216 J
108 J
Energy dissipated (in joules) is E = P × t, with P = V^2/R = (9V)^2/30? = 2.7W. Over 120 seconds, E = 2.7W × 120s = 324J. Converting time to seconds is crucial in energy calculations. DC power and energy.
What is the equivalent resistance of three resistors (8?, 8?, and 4?) connected in parallel?
4?
8?
2?
10?
For three parallel resistors, 1/R_total = 1/8 + 1/8 + 1/4 = 0.125 + 0.125 + 0.25 = 0.5, so R_total = 1/0.5 = 2?. Parallel combinations reduce net resistance below the smallest individual resistor. Parallel resistor networks.
What is the time constant (?) of an RC circuit with R = 1k? and C = 100µF?
0.01 s
10 s
0.1 s
1 s
The time constant ? for an RC circuit is ? = R × C. Substituting R = 1000? and C = 100×10^-6 F gives ? = 1000 × 0.0001 = 0.1 seconds. The time constant indicates how quickly the capacitor charges or discharges. RC time constant details.
In a purely resistive AC circuit, what is the phase difference between current and voltage?
They are in phase
Current leads voltage by 90°
They are 180° out of phase
Voltage leads current by 90°
In purely resistive AC circuits, voltage and current reach their maximum and zero values simultaneously, meaning they are in phase with zero phase difference. This characteristic changes when reactive components (capacitors or inductors) are added. Resistance and phase in AC circuits.
How does the capacitive reactance (Xc) of a capacitor change as the frequency increases?
Xc remains constant
Xc decreases
Xc increases
Xc becomes infinite
Capacitive reactance is Xc = 1/(2?fC), so as frequency (f) increases, the denominator increases, making Xc smaller. Lower reactance at higher frequencies allows more AC current to pass through the capacitor. Understanding capacitive reactance.
A 12V battery has an internal resistance of 1? and supplies a current of 2A. What is the terminal voltage under load?
2 V
14 V
12 V
10 V
Terminal voltage Vt = E - I × r, where E is emf, I is load current, and r is internal resistance. Here Vt = 12V - (2A × 1?) = 10V. Internal resistance causes voltage drop within the battery when current flows. Battery internal resistance explained.
Using the same battery (12V, internal resistance 1?) supplying 2A, how much power is dissipated internally?
2 W
4 W
12 W
6 W
Power dissipated in the internal resistance is P = I^2 × r. Substituting I = 2A and r = 1? gives P = (2^2) × 1 = 4 watts. This internal power loss reduces the energy delivered to the external circuit. Power loss in resistances.
Which technique is used to simplify a network when resistors are neither purely in series nor purely in parallel?
Delta-star (?-Y) transformation
Thevenin's theorem
Maximum power transfer theorem
Superposition theorem
Delta-star (also called ?-Y) transformation is used to convert resistors in a triangular (delta) configuration into an equivalent star (Y) configuration or vice versa. This allows simplification of complex networks that combine series and parallel elements. It is especially useful in bridge circuits. Delta-star transformation.
Which theorem allows you to replace a complex linear circuit by an equivalent voltage source and series resistance?
Superposition theorem
Norton's theorem
Thevenin's theorem
Millman's theorem
Thevenin's theorem states that any two-terminal linear circuit can be reduced to a single voltage source (Vth) in series with a resistance (Rth), making analysis of load variations simpler. It is extensively used in circuit design and analysis. Thevenin's theorem details.
Which configuration represents a Norton equivalent circuit?
Current source in parallel with resistor
Voltage source in parallel with resistor
Current source in series with resistor
Voltage source in series with resistor
Norton's theorem states that any two-terminal linear circuit can be represented by an equivalent current source in parallel with a single resistor. This is the dual of Thevenin's equivalent. Norton and Thevenin conversions are interrelated. Norton's theorem explained.
Which formula expresses electrical power in a circuit using voltage and current?
P = E × I
P = I × R
P = E × R
P = E / I
Electrical power (P) can be calculated as the product of voltage (E) and current (I), so P = E × I. This fundamental relationship is used to determine power consumption in electrical devices. Combined with Ohm's Law, it can be written in other forms. Power formulas in DC circuits.
Approximately what is the capacitive reactance (Xc) of a 30µF capacitor at 1kHz?
53 ?
0.5 ?
5 ?
530 ?
Capacitive reactance is given by Xc = 1/(2?fC). Substituting f = 1000Hz and C = 30×10^-6F yields Xc ? 1/(2?×1000×30e-6) ? 5?. This shows how capacitors impede AC differently at various frequencies. Capacitive reactance calculation.
Under what condition does a load in a circuit receive maximum power according to the Maximum Power Transfer Theorem?
Load resistance is half the source resistance
Load resistance is zero
Load resistance equals source (Thevenin) resistance
Load resistance is twice the source resistance
The Maximum Power Transfer Theorem states that maximum power is delivered to the load when the load resistance equals the source's Thevenin (or internal) resistance. At this point, power transfer efficiency is 50%. This principle guides matching in communication and power systems. Maximum power transfer details.
Why is it generally not recommended to connect two voltage sources of unequal emf directly in parallel?
They produce zero net voltage
They share current equally
Excessive circulating current flows between them
They reduce overall internal resistance
Connecting voltage sources of different emf values in parallel creates a voltage difference that drives a large circulating current between the sources. This can cause overheating, damage to the sources, and potential safety hazards. Manufacturers advise against paralleling unmatched supplies. Parallel power supply considerations.
0
{"name":"Which unit is used to measure electric current?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"Which unit is used to measure electric current?, In conventional current flow, electrons are assumed to move from:, Which material is considered an electrical conductor?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Study Outcomes

  1. Identify Key Components -

    Learn to recognize basic electronic parts such as resistors, capacitors, inductors, diodes, and transistors, and understand their primary functions within simple circuits.

  2. Understand Circuit Principles -

    Grasp fundamental concepts like Ohm's Law, series and parallel connections, and how voltage, current, and resistance interact in electronic systems.

  3. Analyze Circuit Behavior -

    Develop the ability to calculate and predict voltage drops, current flow, and resistance values in various circuit configurations.

  4. Apply Schematic Interpretation -

    Use standard schematic symbols to read and construct simple electronic diagrams, improving your ability to visualize and plan circuits.

  5. Differentiate Component Types -

    Distinguish between passive and active components, and understand when to use each type within foundational naval electronics applications.

  6. Evaluate Knowledge Progress -

    Test your skills, track your quiz performance, and identify areas for improvement as you prepare for advanced Navy electronics modules.

Cheat Sheet

  1. Ohm's Law Essentials -

    Review the V=IR relationship showing how voltage, current, and resistance interact in any circuit. For example, a 9 V source across a 3 Ω resistor yields I=3 A. Mnemonic trick: "VIRgin Mary" to recall Voltage=Current×Resistance effortlessly.

  2. Series and Parallel Networks -

    Master Rs=R1+R2+… for series and 1/Rp=1/R1+1/R2+… for parallel connections to solve complex circuits. In a series chain of 2 Ω and 4 Ω, Rs=6 Ω illustrating simplicity. Practice this for the electronics fundamentals quiz to reinforce analysis speed.

  3. Kirchhoff's Laws -

    Use Kirchhoff's Current Law (∑Iin=∑Iout) and Voltage Law (∑V=0) to verify current flow and voltage drops in multi-node circuits. At any junction, currents balance, and around any loop, voltages sum to zero. Applying these in circuit analysis will boost confidence when tackling NEETS Module 1 quiz problems.

  4. Energy in Reactive Components -

    Remember energy stored in a capacitor (E=½CV²) and in an inductor (E=½LI²). For instance, a 10 µF capacitor charged to 5 V stores (1/2)×10×10^-6 F×(5 V)^2 = 125 µJ. This insight is critical for understanding transient response in Navy electronics modules.

  5. Resistor Color Code Memory -

    Use mnemonic "Black Bears Read Orange Yellow Glass Bottles Very Gracefully Wrapped" to recall Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White. For example, Red-Red-Brown decodes to 2-2×10¹=220 Ω. Speedy color decoding is essential for acing the electronics basics test.
