SOLIDWORKS Essentials Knowledge Test Quiz

Assess core CAD modeling skills in this quiz

Difficulty: Moderate
Questions: 20
Learning OutcomesStudy Material
Colorful paper art depicting a trivia quiz on SOLIDWORKS Essentials Knowledge Test.

Ready to master your SOLIDWORKS skills? This free SOLIDWORKS Essentials knowledge test is perfect for students, educators, and professionals aiming to sharpen foundational CAD modeling techniques. With 15 multiple-choice questions covering sketches, part modeling, assembly constraints and drawing creation, participants will get immediate feedback to identify strengths and learning gaps. Feel free to tweak questions in our editor to create a customized assessment. Explore more quizzes or sharpen other skills with the I/O Systems Knowledge Test and Employee Safety Knowledge Test .

Which SOLIDWORKS interface component displays the hierarchical list of features and sketches?
FeatureManager Design Tree
CommandManager
PropertyManager
Graphics Area
The FeatureManager Design Tree shows the ordered list of features, sketches, and reference geometry in a model. It is the primary way to navigate and edit model history.
Which toolbar provides tabbed access to sketch, features, evaluate, and other commands?
CommandManager
Heads-up View Toolbar
Task Pane
Menu Bar
The CommandManager is a context-sensitive, tabbed toolbar that organizes commands into Sketch, Features, Evaluate, and other tabs. It adapts automatically based on the active environment.
When creating 2D geometry in SOLIDWORKS, which environment must you enter?
Sketch
FeatureManager
Motion Study
Drawing
To create 2D profiles you must enter the Sketch environment on a plane or face. Sketch mode provides all the drawing tools and relations needed to define 2D geometry.
Which sketch tool draws a rectangle by specifying two opposite corners?
Corner Rectangle
Center Rectangle
Line
Ellipse
Corner Rectangle uses two opposite corner points to define the rectangle. Center Rectangle instead uses a center point and a corner point.
Which feature adds material by pulling a 2D sketch perpendicular to its plane?
Extruded Boss/Base
Revolved Boss/Base
Swept Boss/Base
Lofted Boss/Base
Extruded Boss/Base creates a solid by extending a closed sketch normal to its plane. Revolve, sweep, and loft use axes, paths, and profiles respectively.
Which sketch relation enforces two lines to remain perpendicular?
Perpendicular
Parallel
Tangent
Collinear
The Perpendicular relation constrains two selected lines to a 90° angle. Other relations like Parallel or Collinear impose different alignment constraints.
What sketch relation makes two line segments share the same straight line?
Collinear
Coincident
Horizontal
Concentric
Collinear forces two line segments onto the same infinite line. Coincident anchors points together, while Concentric applies to circular entities.
Which sketch tool would you use to draw a circle given its center point?
Centerpoint Circle
Perimeter Circle
Arc
Ellipse
Centerpoint Circle uses a selected center and a perimeter point to define the circle. Perimeter Circle would require two perimeter points.
Which feature removes material by extruding a sketch profile through the part?
Extruded Cut
Revolved Cut
Lofted Cut
Swept Cut
An Extruded Cut removes material by projecting a sketch normal to its plane. Other cut types use revolve, sweep, or loft operations.
In an assembly, which mate aligns two cylindrical faces so they share the same axis?
Concentric Mate
Coincident Mate
Parallel Mate
Angle Mate
Concentric Mate constrains two coaxial cylindrical, conical, or spherical faces to share an axis. Coincident aligns planar faces instead.
When inserting a model into a drawing, which view is automatically placed first?
Front View
Isometric View
Top View
Right View
Front View is the default primary view when you insert a model into a drawing. Other projected views derive from that initial orientation.
Which tool in a drawing is used to annotate the diameter of a circular feature?
Smart Dimension
Auto Balloon
Note
Center Mark
Smart Dimension allows you to select circle edges and place a diameter dimension. Center Marks add reference points but not dimensional values.
Which assembly tool checks for overlapping solid geometry between components?
Interference Detection
Collision Detection
Path Measurement
Smart Fastener
Interference Detection analyzes components for overlapping solid volumes. Collision Detection is used during motion studies rather than static interference checks.
In a Motion Study, which study type uses realistic physics and forces?
Motion Analysis
Animation
Basic Motion
Flow Simulation
Motion Analysis (COSMOSMotion) applies true physical properties like mass and forces. Animation and Basic Motion are simplified kinematic simulations.
Which drawing view type projects geometry orthogonally from a selected parent view?
Projected View
Auxiliary View
Section View
Detail View
Projected View takes a parent view and projects it at 90° to create standard orthographic views. Auxiliary is angled projection, and section/detail show cuts or zoomed areas.
Which loading mode opens parts with reduced detail to improve performance in large assemblies?
Lightweight
Large Assembly Mode
Determinant Mode
Detail Mode
Lightweight mode loads only essential faces and bodies, speeding up manipulation of large assemblies. Large Assembly Mode affects display settings but does not change load detail.
Which mate type restricts the relative angular movement of two components within specified limits?
Limit Angle Mate
Angle Mate
Lock Mate
Width Mate
Limit Angle Mate lets you specify minimum and maximum angles between components. Angle Mate fixes a single angle but does not define a range.
What file extension is used for a SOLIDWORKS drawing template?
.drwdot
.sldprt
.sldasm
.sldedt
.drwdot is the template file type for SOLIDWORKS drawings, storing sheet format, title block, and other default settings. Part templates use .prtdot.
Which feature creates multiple instances of components or features following a selected path curve?
Curve-Driven Pattern
Linear Pattern
Mirror
Circular Pattern
Curve-Driven Pattern places copies of a feature or component along a selected curve. Circular and linear patterns use axes or directions instead.
When entering an equation into a dimension field, which character must precede the expression?
=
#
/
>
Equations in SOLIDWORKS dimensions must begin with '=' to indicate a formula rather than a static value. Other characters are not recognized for equations.
0
{"name":"Which SOLIDWORKS interface component displays the hierarchical list of features and sketches?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"Which SOLIDWORKS interface component displays the hierarchical list of features and sketches?, Which toolbar provides tabbed access to sketch, features, evaluate, and other commands?, When creating 2D geometry in SOLIDWORKS, which environment must you enter?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Learning Outcomes

  1. Identify key SOLIDWORKS interface components and their functions
  2. Apply sketching principles to create foundational 2D geometry
  3. Demonstrate part modeling workflows with extrude and revolve features
  4. Analyse assembly constraints and motion principles in SOLIDWORKS
  5. Evaluate drawing creation skills for technical documentation
  6. Master best practices for design efficiency and feature management

Cheat Sheet

  1. Familiarize Yourself with the SOLIDWORKS Interface - Jump right into the Command Bar, FeatureManager Design Tree, and Property Manager to navigate like a seasoned CAD artist. Understanding where each tool lives saves you clicks and frustration. Embrace the interface and watch your modeling speed soar. Major User Interface Components
  2. Master Sketching Principles - Use construction lines, relations, and dimensions to fully define your sketches and avoid unpredictable edits later on. A rock-solid 2D foundation turns your 3D designs into reality without extra headaches. Sketch smartly and let your creativity flow. 3 Tips and Tricks for 2D Sketching
  3. Apply Best Practices in Part Modeling - Start with basic extrudes and cuts, then layer on more complex features once the groundwork is solid. Use feature patterns to replicate geometry instead of reinventing the wheel. This keeps your parts clean, robust, and easy to update. Guide to SOLIDWORKS Best Practices
  4. Understand Assembly Constraints - Mates and constraints are the glue that holds your assembly together, controlling how parts move and fit. Learn the difference between coincident, concentric, and distance mates to avoid wobbles and gaps. Proper constraints ensure everything plays nicely. Assembly Constraint Order
  5. Optimize Assembly Performance - Break large projects into sub-assemblies and limit configurations to keep SOLIDWORKS running smoothly. Fewer open components mean faster rebuilds and less lag. A nimble assembly is a joy to work with, even on a busy desktop. Best Practices for Assemblies
  6. Develop Technical Drawings - Transform your 3D models into clear, detail-packed blueprints with proper views, dimensions, and tolerances. Good drawings communicate intent flawlessly to manufacturers and teammates. Sharpen this skill to bridge design and production with confidence. Technical Drawings Guide
  7. Implement Design Efficiency Practices - Draft faces before fillets and add cleanups last to maintain a flexible feature tree. Early planning of drafts and chamfers prevents rebuild errors and makes edits a breeze. Adopt these golden rules for a smoother modeling journey. The 10 Golden Rules of Solid Modeling
  8. Utilize Configurations - Manage multiple design variations in one file by toggling features, dimensions, or suppression states. Configurations let you test options and produce part families without juggling separate documents. It's like having a design Swiss Army knife. Configurations Overview
  9. Employ Smart Dimensioning Techniques - Combine dimensions and geometric relations to lock down sketches completely. Over-dimensioning clutters your canvas; under-dimensioning leads to weak designs. Find the perfect balance for predictable edits and bullet-proof geometry. 3 Tips and Tricks for 2D Sketching
  10. Regularly Review and Optimize Models - Run interference checks, fix rebuild errors, and confirm that all mates work as intended. Routine model audits catch issues early, keeping your project on track and high-quality. A little maintenance goes a long way in CAD world! Interference Detection
