Take the GD&T Knowledge Assessment Quiz

Assess Your Geometric Dimensioning and Tolerancing Skills

Difficulty: Moderate
Questions: 20
Learning OutcomesStudy Material
Colorful paper art depicting GDT Knowledge Assessment Quiz theme.

Want to test your GD&T expertise? This Knowledge Assessment Quiz challenges you with precision measurement scenarios to sharpen your skills. It's perfect for engineers, quality inspectors, and students seeking to master geometric dimensioning and tolerancing. You can also compare your understanding with our Product Knowledge Assessment Quiz or tailor questions freely in our editor. Explore more quizzes and keep advancing in GD&T.

Which GD&T symbol indicates perpendicularity?




The symbol denotes perpendicularity between two features or surfaces. The symbol indicates parallelism, and the other symbols represent circularity or concentricity. Perpendicularity ensures a 90 relationship.
What type of geometric tolerance is specified by the symbol ?
Flatness
Position
Straightness
Circularity
The symbol stands for positional tolerance, which controls the location of a feature relative to datums. Straightness, flatness, and circularity are different form tolerances. Positional tolerance ensures the feature's center is within a specified tolerance zone.
In a datum reference frame labeled A|B|C, which datum has the highest priority?
C
All are equal
B
A
Datum A is the primary datum and has the highest priority for establishing the part's origin and orientation. Datum B is secondary, and datum C is tertiary. The order A|B|C dictates that priority.
What does the modifier MMC stand for in GD&T?
Maximum Material Condition
Required Material Condition
Minimum Material Condition
Material Mean Condition
MMC stands for Maximum Material Condition, referring to the condition where a feature of size contains the most material (largest shaft or smallest hole). LMC refers to the opposite. MMC is used to calculate bonus tolerance and virtual condition.
Which GD&T tolerance controls the flatness of a surface?
Straightness
Profile
Flatness
Concentricity
Flatness tolerance controls how much a surface can deviate from an ideal plane. Straightness controls a line element, profile controls complex contours, and concentricity controls central axes. Flatness ensures no undulation across the indicated surface.
What shape is the tolerance zone for positional tolerance when no material condition modifier is applied?
Cylindrical
Rectangular
Circular
Spherical
Without a material condition modifier, positional tolerance defines a circular (2D) zone within which the feature center must lie. Cylindrical zones apply to axis-centric features and spherical to 3D points. Rectangular zones are not used for positional tolerance.
A hole is offset by 0.10 mm in X and 0.20 mm in Y. What is the true position error?
0.24 mm
0.30 mm
0.22 mm
0.17 mm
True position error is calculated by (0.10 + 0.20) 0.2236 mm, rounded to 0.22 mm. This represents the radial distance from the nominal location. It must be within the positional tolerance zone.
In GD&T, what does the term 'virtual condition' refer to?
The theoretical perfect form of a feature
The free-state condition of a part
A maximum envelope for datum targets
The worst-case boundary combining size and geometric tolerance
Virtual condition is the worst-case boundary that results from combining the MMC size and the associated geometric tolerance. It defines the limit the feature must not violate. It is used for functional gaging and assembly clearance checks.
When a feature uses the MMC modifier, any reduction in material allows extra tolerance. What is this extra tolerance called?
Tolerance stack-up
Bonus tolerance
Free-state tolerance
Virtual tolerance
Bonus tolerance is the additional geometric tolerance granted when a feature departs from its MMC size toward LMC. It is calculated as actual size minus MMC. It allows more positional or form variation as the part gets smaller (for holes) or larger (for shafts).
Composite positional tolerance uses how many tolerance zones?
Four
Two
Three
One
Composite positional tolerance consists of two tolerance zones: one for the pattern as a whole and one for individual feature variation. This approach controls both location consistency across the pattern and precise individual placement.
Which symbol in a feature control frame indicates the Maximum Material Condition modifier?
L
S
F
M
The letter 'M' inside a feature control frame indicates the MMC modifier. 'L' indicates LMC, 'S' is typically used for projected tolerance, and 'F' is used for fixed-size tolerance. MMC governs bonus tolerance calculation.
Which GD&T tolerance controls the angular orientation of a surface relative to a datum?
Perpendicularity
Angularity
Parallelism
Concentricity
Angularity tolerance controls the angle between a feature and its datum reference. Perpendicularity and parallelism control 90 and 0 angles respectively, and concentricity controls axes alignment.
What does the modifier RFS stand for in a feature control frame?
Residual Free Surface
Regardless of Feature Size
Resultant Feature Size
Required Free State
RFS stands for 'Regardless of Feature Size,' meaning no bonus tolerance is allowed and the geometric tolerance is constant at all feature sizes. It is the default condition when no modifier is specified.
In the feature control frame "0.2 M A B", what does 'M' represent?
Material Mean Condition
Least Material Condition
Maximum Material Condition
Mathematical Feature Size
In the frame "0.2 M A B", 'M' specifies that the 0.2 positional tolerance applies at Maximum Material Condition. This allows bonus tolerance as the feature departs from MMC.
Which GD&T symbol is used to control profile of a surface?




The profile of a surface symbol () controls the 3D shape of a feature relative to its true profile. The angle symbol () is for angularity, is for diameter or circularity, and is for perpendicularity.
A hole is 10 +0.02/0.00 mm with a positional tolerance 0.1 mm at MMC. What is the virtual condition diameter?
10.10 mm
9.98 mm
9.90 mm
10.12 mm
For a hole, MMC is its smallest size (10.00 mm). Virtual condition = MMC size minus positional tolerance = 10.00 mm 0.10 mm = 9.90 mm. It represents the smallest allowable boundary for functional gauging.
In composite positional tolerance 0.2 A B C (pattern) and 0.05 A (individual), what does the 0.05 tolerance control?
Feature form
Individual feature variation
Total runout
Overall pattern location
The second segment (0.05 A) controls individual feature variation relative to datum A. The first segment controls the pattern as a whole. This separation ensures tight individual placement as well as uniform pattern location.
Profile of a surface tolerance can reference up to how many datums to fully constrain all degrees of freedom?
Three
None
Two
One
Profile of a surface can use up to three datums (primary, secondary, tertiary) to constrain all six degrees of freedom of a surface feature. Fewer datums leave some degrees unconstrained.
What is the maximum permissible positional tolerance at MMC for a hole if the basic positional tolerance is 0.1 mm and the actual hole size is 9.95 mm (tolerance 10.00/0.05)?
0.10 mm
0.05 mm
0.20 mm
0.15 mm
MMC for the hole is its smallest size, 9.95 mm. Since actual hole size equals MMC, bonus tolerance = 9.95 mm 9.95 mm = 0.00 mm. Therefore, maximum permissible positional tolerance remains the basic 0.1 mm.
A shaft is 20.00 +0.00/0.02 mm with total runout tolerance 0.03 mm at MMC. What is the maximum diameter of the GO gauge for this shaft?
19.98 mm
20.00 mm
20.05 mm
20.03 mm
For a shaft, MMC size is its largest material condition (20.00 mm). The GO gauge diameter = MMC size + total runout tolerance = 20.00 mm + 0.03 mm = 20.03 mm. This ensures any shaft within tolerance will pass.
0
{"name":"Which GD&T symbol indicates perpendicularity?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"Which GD&T symbol indicates perpendicularity?, What type of geometric tolerance is specified by the symbol ?, In a datum reference frame labeled A|B|C, which datum has the highest priority?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Learning Outcomes

  1. Analyse feature control frames to determine tolerance specifications
  2. Apply geometric dimensioning and tolerancing symbols accurately on part drawings
  3. Identify datums and reference frames for proper measurement setup
  4. Evaluate the effects of material condition modifiers like MMC and LMC
  5. Demonstrate understanding of form, orientation, and location tolerances
  6. Master calculation of positional tolerance zones

Cheat Sheet

  1. Understand the ASME Y14.5 Standard - Dive into the ASME Y14.5 guidelines to nail GD&T fundamentals and interpret engineering drawings like a pro. This standard is your roadmap to symbols, tolerances, and dimensioning rules. Knowing it inside out means fewer red”pen corrections and more "A+" schematics. en.wikipedia.org
  2. Master GD&T Symbols and Modifiers - Get friendly with symbols for flatness, straightness, circularity and more, so you can speak "engineer" fluently. These little icons carry big meaning - nail them and you'll avoid costly miscommunications. Practice charting them in study cards for extra fun. qualitymag.com
  3. Analyze Feature Control Frames - Feature control frames are the blueprints for allowable variation; learn to read them as if they were treasure maps. Each box tells you what's required, from tolerance values to datum references. Cracking their code means fewer fit-up hiccups. learn.toolingu.com
  4. Identify Datums and Reference Frames - Datums are your north stars in measurement setups; identify them correctly and your parts will line up perfectly every time. These reference points keep everything in check - imagine building a house without a solid foundation! qualitymag.com
  5. Apply Material Condition Modifiers - Discover how MMC (Maximum Material Condition) and LMC (Least Material Condition) can give you bonus tolerance when parts grow or shrink. These modifiers are like getting extra points on a test - use them wisely to boost your design flexibility. solidprofessor.com
  6. Understand Form Tolerances - Form tolerances control the shape of features - flatness keeps surfaces planar, straightness tames lines, and circularity shapes your curves. Master these to ensure parts fit together smoothly and look as precise as a pro's. sae.org
  7. Grasp Orientation Tolerances - Orientation tolerances like perpendicularity, parallelism, and angularity make sure features align correctly in 3D space. Perfecting these means you'll sketch cubes and cylinders that stack and mate seamlessly. sae.org
  8. Comprehend Location Tolerances - Location tolerances - position, concentricity, and symmetry - dictate where features should sit within a part. Lock down these rules to prevent misaligned holes or mismatched bosses when you assemble. sae.org
  9. Calculate Positional Tolerance Zones - Sharpen your math skills by working out positional tolerance zones that define allowable feature shifts. These calculations ensure holes, pins, and slots play nice together without binding or wobbling. asme.org
  10. Apply GD&T in Real-World Scenarios - Bring theory to life with hands-on projects: measure parts, inspect samples, and troubleshoot GD&T callouts on actual components. This practical play cements concepts and builds confidence for the shop floor. sae.org
