How many semiconductor layers make up the basic structure of an SCR?
Two
Five
Four
Three
An SCR is composed of four alternating P and N semiconductor layers forming a PNPN structure. This four-layer arrangement allows the device to latch into conduction once it is triggered. The internal regenerative feedback between the two transistor models in this PNPN stack maintains the on-state until the current falls below the holding level. For more details, see Electronics Tutorials.
Which terminal is used to trigger an SCR into conduction?
Base
Anode
Gate
Cathode
The gate terminal of an SCR injects charge carriers to initiate conduction through the PNPN structure. Once a sufficient gate pulse is applied, the device latches on and remains conducting until the current falls below the holding level. The anode and cathode serve as the main current path and are not used for triggering. You can read more at Electronics Tutorials.
After an SCR is triggered and conducting, what mechanism keeps it in the on-state even if the gate signal is removed?
Thermal feedback
Gate leakage
Regenerative feedback
Magnetic coupling
SCRs employ regenerative feedback between the two transistor equivalents within their PNPN layers to maintain conduction. Once the device latches on, this positive feedback sustains the on-state until the anode current drops below the holding current. The gate signal is only needed to initiate conduction; it plays no role in sustaining it. Further explanation is available at All About Circuits.
What is the behavior of an SCR when the anode-to-cathode voltage is reversed?
It conducts in reverse
It self-triggers
It latches on permanently
It blocks the voltage
When reverse-biased, the SCR's PNPN structure inhibits current flow by blocking the applied voltage. No conduction occurs until the reverse breakdown voltage is reached, which would damage the device. This reverse-blocking capability is one of the key features of SCRs in power applications. For more information, visit Electronics Notes.
What is the holding current of an SCR?
The current at which forward voltage falls to zero
The maximum load current the SCR can handle
The minimum anode current required to maintain conduction
The minimum gate current needed to turn on
The holding current (IH) is the lowest anode current that will keep the SCR in its conducting state once it has been triggered. If the current drops below this level, the device will turn off. This parameter is critical in designing commutation circuits and ensuring reliable turn-off. See TI Application Note for more details.
Which of the following is NOT a recognized method to turn off an SCR in a DC circuit?
Applying a reverse voltage across the SCR
Reducing the load current below the holding current
Using a commutation circuit
Applying a negative gate pulse
Turning off an SCR in a DC circuit typically requires commutation techniques or forcing the current below the holding current, not by a negative gate pulse. The gate loses control once the device is latching. Reverse biasing with a commutation circuit (voltage or resonant) is the usual method. More can be found at Electronics Tutorials.
In an AC circuit, how does natural commutation turn off an SCR?
By cooling the device rapidly
By momentarily shorting the SCR
By reversing the AC voltage during each cycle
By applying a reverse gate pulse
Natural commutation in AC circuits relies on the alternating supply voltage reversing polarity each half-cycle. When the AC voltage goes negative relative to the conducting direction, it forces the anode current below the holding current, turning the SCR off. This method requires no extra components, making it common in AC applications. Learn more at All About Circuits.
What is the typical forward voltage drop of a silicon-based SCR when conducting?
Approximately 5 V
Approximately 1.2 V
Approximately 2.5 V
Approximately 0.7 V
When an SCR is in the on-state, it typically exhibits a forward voltage drop around 1.2 V, similar to silicon diodes but slightly higher due to the four-layer structure. This voltage drop results in conduction losses that must be accounted for in power designs. Exact values vary by device rating and manufacturer. See typical datasheet specifications at STMicroelectronics.
How does adding a resistor in series with the gate and cathode influence SCR triggering?
Prevents false triggering by limiting gate current
Lowers the on-state voltage drop
Increases dv/dt sensitivity
Eliminates the need for commutation circuits
A series gate resistor limits the gate current and slows the rise time of gate voltage, reducing dv/dt sensitivity and preventing unintended turn-on from transients. This helps avoid false triggering due to noise or rapid voltage changes. The resistor must be sized to ensure reliable gate drive while improving noise immunity. For design guidelines, see ON Semiconductor Application Note.
What undesirable effect can a high dv/dt across an SCR cause?
Delayed turn-on time
Automatic commutation
Decreased holding current
False triggering of the device
A high rate of voltage change (dv/dt) across the anode-to-cathode terminals can induce capacitive currents within the SCR structure, inadvertently driving it into conduction without a gate pulse. This false triggering is often mitigated with snubber circuits or gate resistors. Designers must ensure that the device's dv/dt rating is not exceeded. More information is at TI Application Note.
In phase-angle control of an AC waveform using an SCR, how is the output power adjusted?
By varying the supply frequency
By changing the device's forward voltage drop
By shifting the conduction angle (firing angle)
By varying the gate pulse width
Phase-angle control adjusts the firing angle ? at which the SCR is triggered each half-cycle of the AC waveform. By delaying or advancing ?, the conduction period is shortened or extended, thus controlling the average output voltage and power. This method is widely used in light dimmers and motor speed controls. For mathematical treatment, see Electronics Tutorials.
What is the average DC output voltage (VDC) of a half-wave controlled rectifier with peak input voltage Vm and firing angle ??
VDC = Vm/?
VDC = Vm(1 - cos ?)/?
VDC = Vm(1 + sin ?)/(2?)
VDC = Vm(1 + cos ?)/(2?)
For a half-wave controlled rectifier, the average output voltage is given by VDC = (Vm/2?)(1 + cos ?), where Vm is the peak AC voltage and ? is the firing angle. This formula accounts for the conduction interval from ? to ? each cycle. Engineers use this relationship to predict and control DC output in power conversion. Detailed derivation is available at Electronics Tutorials.
0
{"name":"How many semiconductor layers make up the basic structure of an SCR?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"How many semiconductor layers make up the basic structure of an SCR?, Which terminal is used to trigger an SCR into conduction?, After an SCR is triggered and conducting, what mechanism keeps it in the on-state even if the gate signal is removed?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}
Score1/12
Easy0/4
Medium0/4
Hard1/3
Expert0/1
AI Study Notes
Email these to me
You can bookmark this page to review your notes in future, or fill out the email box below to email them to yourself.
Study Outcomes
Analyze SCR Structure and Function -
Examine the layers and junctions of a semiconductor controlled rectifier to understand how its construction influences conduction and switching characteristics.
Apply SCR Working Principles to Circuit Design -
Use the scr working principle to predict device behavior and configure simple rectifier circuits for controlled power delivery.
Evaluate SCR Circuit Operation Under Varying Conditions -
Assess scr circuit operation by analyzing how voltage, current, and temperature variations impact performance and reliability.
Interpret Gate Triggering Techniques for Silicon Controlled Rectifiers -
Compare triggering methods such as latching, dv/dt control, and gate pulse variations to optimize gate control strategies.
Solve Thyristor Test Questions to Enhance Diagnostic Skills -
Tackle targeted thyristor test questions to sharpen troubleshooting strategies and validate your mastery of SCR concepts.
Cheat Sheet
SCR Structure and PNPN Layers -
The semiconductor controlled rectifier consists of four alternating P and N semiconductor layers forming three junctions (J1, J2, J3), as outlined by MIT OpenCourseWare. Knowing the PNPN sequence helps in visualizing carrier injection and blocking action in a silicon controlled rectifier. Use the mnemonic "P-N-P-N: Power Now, Power Next" to recall the layer order easily.
Gate Triggering and Holding Principles -
Key to scr working principle is the gate current (I_G), which forward-biases J2 and initiates avalanche multiplication; IEEE reports typically specify gate trigger voltage (V_GT) and current (I_GT) for reliable turn-on. Once conduction starts, holding current (I_H) must be maintained to keep the device on, with I_H often <10% of I_GT. Think "Start at Gate, Stay at Hold" to differentiate trigger and holding phases.
Latching Current and Turn-On Dynamics -
Latching current (I_L) is the minimum anode current needed to lock the SCR into conduction, per Texas Instruments application notes on thyristor test questions. Exceeding I_L in under 10 µs ensures the device remains latched; if not, the SCR reverts to the off state. A sample relation is I_L≈0.3·I_T (where I_T is rated on-state current) as a rule of thumb in high-power circuits.
Forward and Reverse Blocking Modes -
In forward blocking mode, junctions J1 and J3 are forward-biased while J2 is reverse-biased, allowing the device to withstand voltages up to its V_DRM rating; reverse blocking flips this condition, per University of Illinois EE course materials. Understanding both modes is critical for safe scr circuit operation in AC drives. Visualize it as two doors: one open, one closed, then vice versa when polarity reverses.
Commutation Techniques and dv/dt Considerations -
Forced commutation methods, such as resonant or complementary commutation, are vital for turning off SCRs in DC circuits, as detailed on Electronics-Tutorials. Designers must also consider the dv/dt rating - exceeding it can trigger unintended turn-on through capacitive coupling. Remember "slow voltage rise, avoid surprise" to manage dv/dt constraints.
