Ultimate Gas Engine Lubrication System Quiz

Think you can ace the gas engine lubrication system functions? Start the quiz now!

Difficulty: Moderate
2-5mins
Learning OutcomesCheat Sheet
Paper art engine with oil droplets cooling fins and labeled lubrication paths on dark blue background for quiz

Are you ready to put your knowledge of the gas engine lubrication system to the test? In this Gas Engine Lubrication System Quiz: Test Your Expertise, you'll discover how the lubrication system lubricates, cools, and cleans engines while mastering gas engine cooling lubrication and engine lubrication system basics. You'll learn how proper oil circulation protects vital engine parts, prevents wear, and enhances performance. Whether you're a mechanic or enthusiast, dive into our Engine Cooling and Lubrication Quiz or test your skills with our engine system components quiz . Embrace the lubrication function in gas engines - challenge yourself and start now!

What is the primary function of the lubrication system in a gas engine?
To reduce friction and wear between moving parts
To increase engine power output
To adjust fuel–air mixture
To control engine timing
The lubrication system supplies oil to engine components to form a protective film that reduces friction and wear. It also helps in cooling and cleaning but its primary role is to prevent metal-to-metal contact. Without proper lubrication, engine parts would rapidly deteriorate. https://en.wikipedia.org/wiki/Lubrication
Which component is responsible for circulating oil under pressure through the engine?
Oil pump
Oil cooler
Oil filter
Oil sump
The oil pump draws oil from the sump and forces it through the lubrication circuit under pressure. This pressurized flow ensures oil reaches bearings and other critical parts. Most gas engines use gear or rotor-type pumps. https://www.machinerylubrication.com/Read/1046/oil-pumps
Where is the engine oil typically stored when the engine is not running?
Oil sump (pan)
Oil gallery
Crankcase breather
Oil cooler inlet
The oil sump, also called the oil pan, is the reservoir at the bottom of the engine where oil collects when the engine stops. From here the pump draws oil to distribute it throughout the engine. Proper sump design ensures adequate oil supply on variations in vehicle orientation. https://en.wikipedia.org/wiki/Oil_pan
What property of engine oil is measured by its viscosity?
Resistance to flow
Flash point
Acid number
Thermal conductivity
Viscosity indicates an oil's resistance to flow; higher viscosity oils are thicker. Engine oils must maintain a balance: thick enough to protect bearings but thin enough to circulate. Viscosity varies with temperature, hence multi-grade oils. https://www.chemistryexpert.org/oil-viscosity.html
Which classification system rates oil by viscosity grades, such as 10W-30?
SAE viscosity grades
API service classification
ISO cleanliness code
ASTM melting point
The Society of Automotive Engineers (SAE) assigns viscosity grades like 10W-30 to engine oils, denoting behavior at cold (W) and hot temperatures. This system helps users choose the right oil for ambient conditions. Multi-grade oils contain additives to maintain viscosity across a temperature range. https://www.sae.org/standards/content/j300_202001/
What component removes particulate contaminants from engine oil?
Oil filter
Oil cooler
Oil pump
Oil gallery
The oil filter traps dirt, metal particles, and other debris as oil circulates. This prevents abrasive wear inside the engine. Filters use paper or synthetic media, and must be replaced at service intervals. https://www.mobil.com/en/lubricants/tools-and-resources/coating-and-filtration/articles/how-oil-filters-work
Which lubrication method relies on gears or crankshafts flinging oil onto components?
Splash lubrication
Pressure lubrication
Mist lubrication
Ring lubrication
In splash lubrication, rotating parts dip into the oil and fling it onto surfaces. This method is simple and used in low-speed or small engines. It does not require a pressurized pump circuit. https://www.machinerylubrication.com/Read/482/splash-lubrication
Why is oil cooling important in a gas engine lubrication system?
To maintain proper oil viscosity and prevent thermal breakdown
To increase oil production rate
To filter out water contamination
To neutralize acids chemically
Engine heat raises oil temperature, reducing its viscosity and protective film strength. Oil coolers remove excess heat, preserving viscosity and additive performance. Proper cooling prevents oil oxidation and sludge formation. https://www.hpacmag.com/technical/engine-cooling-systems/
What does the API service classification on engine oil indicate?
Performance standards for engine protection
Exact oil viscosity at operating temperature
Oil filter compatibility
Pump flow rate
The API service classification (e.g., API SN, CK-4) defines benchmarks for wear protection, deposit control, and sludge prevention. It ensures the oil meets engine manufacturer requirements. Using the correct classification maintains warranty and performance. https://www.api.org/products-and-services/engine-oil
Which additive is primarily used to improve the viscosity index of engine oil?
Polyisobutylene (PIB) viscosity index improvers
Zinc dialkyldithiophosphate (ZDDP)
Detergent dispersants
Pour point depressants
Viscosity index improvers like PIB are polymers that expand at high temperature to prevent thinning of the oil. They help multi-grade oils maintain a stable viscosity range. ZDDP provides antiwear protection, not VI improvement. https://www.lubrizol.com/Learn/Engine-Oil-Additives/Viscosity-Index-Improvers
What is the main difference between full-pressure and splash lubrication systems?
Full-pressure uses a pump to deliver oil under pressure; splash relies on moving parts flinging oil
Splash uses a pump; full-pressure relies on gravity
Full-pressure is only for manual transmissions
Splash requires oil coolers; full-pressure does not
Full-pressure lubrication employs an oil pump to force oil through galleries to bearings and camshafts. Splash lubrication depends on mechanical parts dipping into oil and throwing it onto surfaces. Full-pressure offers more consistent film thickness at high speeds. https://www.machinerylubrication.com/Read/72/full-vs-splash-lubrication
In lubrication, what is the boundary lubrication regime characterized by?
Direct surface contact with protective additive films
Hydrodynamic oil film fully separating surfaces
No relative motion between surfaces
Complete absence of additives
Boundary lubrication occurs at start/stop or heavy load when the oil film is too thin to separate surfaces completely. Additives like ZDDP form a protective film to prevent wear. Hydrodynamic lubrication is a different regime where a full fluid film separates surfaces. https://www.machinerylubrication.com/Read/615/boundary-lubrication
Which oil analysis parameter indicates acid formation and corrosion risk in engine oil?
Total Acid Number (TAN)
Soot count
Water content
Viscosity index
TAN measures the acidic compounds formed by oil oxidation and contamination. A rising TAN warns of increased corrosion risk. Monitoring TAN helps determine when to change oil. https://www.stle.org/files/TLTArchives/2017/May/4Chester.pdf
What is the purpose of the bypass valve in an engine oil filter?
To allow oil to bypass the filter when it is clogged
To regulate oil temperature
To control oil viscosity
To measure oil pressure
If the filter element becomes too restrictive, the bypass valve opens, allowing unfiltered oil to circulate and prevent oil starvation. This protects the engine at high contamination levels. It is a safety feature, not a primary flow control. https://www.mobil.com/en/lubricants/learning-center/filters-and-filtration
Why is a drop in oil pressure often an early indicator of a clogged oil filter?
Filter restriction reduces pump output pressure
Oil viscosity decreases
Oil temperature rises
Oil sump level increases
As debris accumulates, the filter element becomes more restrictive, causing pump pressure to drop. The engine’s oil pressure gauge or sensor detects this reduction. The bypass valve may open at extreme blockage, but a general drop precedes that action. https://www.enginebuildermag.com/2019/06/pressure-drops-guide/
Which principle explains the formation of a full hydrodynamic oil film between journal bearings and shafts?
Pressure build-up in converging wedge of lubricant
Magnetic attraction between surfaces
Capillary action in bearing clearances
Static surface roughness locking
Hydrodynamic lubrication occurs when relative motion drags oil into a narrowing gap, generating pressure that supports the load. This pressure separates the surfaces fully. The converging wedge effect is fundamental to bearing film formation. https://en.wikipedia.org/wiki/Hydrodynamic_lubrication
What does the lambda ratio (?) represent in bearing lubrication analysis?
Ratio of oil film thickness to combined surface roughness
Ratio of oil viscosity to temperature
Ratio of oil pressure to bearing load
Ratio of oil flow rate to clearance
Lambda ratio compares film thickness to surface roughness of the bearing and journal. A higher ? indicates a thicker film relative to roughness, reducing wear. It helps predict lubrication regime and potential metal contact. https://www.ncbi.nlm.nih.gov/pmc/articles/PMC6491994/
What is the primary advantage of a trochoid (rotor) oil pump over a gear pump?
Higher volumetric efficiency and more uniform flow
Lower manufacturing cost
No need for seals
Better water separation
Trochoid pumps use inner and outer rotors to deliver fluid with minimal pulsation and high volumetric efficiency. They maintain flow at varying speeds better than gear pumps. This leads to more consistent oil pressure. https://www.machinerylubrication.com/Read/443/trochoid-pumps
Why is oil deaeration important in lubrication systems?
Air entrained in oil can cause cavitation and reduce film strength
It increases oil acidity
It removes water contamination
It improves viscosity index
Air bubbles in oil collapse under pressure, leading to cavitation damage and loss of film integrity. Deaeration ensures continuous, stable film and consistent pressure. It is critical for protecting bearings and pumps. https://www.stle.org/files/TLTArchives/2018/April/4Sergio.pdf
How does a centrifugal oil cleaner differ from a traditional filter?
It removes fine particles by centrifugal force rather than by media trapping
It only cools oil, not filter it
It uses magnetic separation
It chemically neutralizes acids
Centrifugal cleaners spin oil at high speed to fling out particles into a sediment chamber. They excel at removing very fine abrasive contaminants. Unlike media filters, they do not clog and have minimal pressure drop. https://www.machinerylubrication.com/Read/320/oil-cleaners
What effect does fuel dilution have on engine oil performance?
It lowers oil viscosity and reduces lubrication protection
It raises oil viscosity and improves film strength
It increases oil flash point
It neutralizes acids
Fuel entering the crankcase dilutes engine oil, reducing its viscosity and protective ability. Lower viscosity weakens the oil film, increasing wear. Fuel contamination also accelerates oxidation and deposits. https://www.sae.org/publications/technical-papers/content/2005-01-3676/
Which curve describes the relationship between friction coefficient, viscosity, speed, and load in lubrication theory?
Stribeck curve
Darcy–Weisbach curve
Arrhenius plot
PV diagram
The Stribeck curve plots friction coefficient against a dimensionless parameter combining viscosity, speed, and load. It illustrates regimes from boundary to mixed to hydrodynamic lubrication. Understanding it helps optimize film thickness and minimize wear. https://en.wikipedia.org/wiki/Stribeck_curve
How does increasing bearing clearance affect hydrodynamic film thickness under a constant load?
Reduces film thickness and increases risk of asperity contact
Increases film thickness and reduces pressure
Has no effect on film thickness
Transforms boundary into hydrodynamic regime
Larger clearance lowers the converging wedge angle, reducing hydrodynamic pressure generation and film thickness. This can lead to metal contact under load. Proper clearance is critical for optimal bearing performance. https://www.sciencedirect.com/topics/engineering/bearing-clearance
What does depletion of Total Base Number (TBN) in engine oil most directly indicate?
Loss of acid neutralizing reserve and increased corrosion risk
Reduction in viscosity index
Presence of water contamination
Increased fuel dilution
TBN measures alkaline additives that neutralize acids formed during combustion. As TBN decreases, the oil’s capacity to neutralize corrosive acids lessens, leading to component corrosion. Monitoring TBN helps schedule timely oil changes. https://www.lube4life.com/TBN.htm
0
{"name":"What is the primary function of the lubrication system in a gas engine?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"What is the primary function of the lubrication system in a gas engine?, Which component is responsible for circulating oil under pressure through the engine?, Where is the engine oil typically stored when the engine is not running?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Study Outcomes

  1. Understand core lubrication functions -

    Learn how a gas engine lubrication system lubricates moving parts to minimize wear and support efficient performance.

  2. Analyze oil flow pathways -

    Trace the journey of lubricating oil through filters, galleries, and bearings to see how each component contributes to smooth operation.

  3. Identify cooling and cleaning mechanisms -

    Explore how the lubrication system cools engine parts and removes contaminants to maintain optimal engine health.

  4. Evaluate maintenance essentials -

    Assess best practices for oil selection, filter replacement, and system inspections to prevent engine damage.

  5. Apply troubleshooting techniques -

    Develop the skills to diagnose common lubrication issues and implement corrective actions for reliable engine performance.

Cheat Sheet

  1. Triple Role of Engine Oil -

    Engine oil in a gas engine lubrication system lubricates, cools, and cleans vital components by forming a thin film, transferring heat, and suspending contaminants for removal. Remember the mnemonic "LCC" (Lubricates, Cools, Cleans) to keep these functions top of mind. According to Penn State's Department of Mechanical Engineering, this trifecta prevents metal-to-metal contact, maintains optimal temperature, and preserves engine cleanliness.

  2. Viscosity Selection and SAE Grading -

    The viscosity of engine oil, denoted by SAE grades (e.g., 10W-30 per SAE J300), dictates flow behavior under various temperatures in a gas engine lubrication system. A lower "W" number improves cold start lubrication, while the second number ensures film strength at operating temperature. Keep in mind the phrase "Winter starts with a low W" to recall how viscosity affects cold-weather performance.

  3. Oil Flow Path and Pressure Regulation -

    The lubrication system relies on a positive-displacement pump to deliver oil from the sump through filters and galleries to bearings and camshafts, ensuring consistent oil flow and pressure (typically 40 - 70 psi at idle; 60 - 80 psi at 3,000 rpm). A relief valve, set by manufacturers like Ford or Toyota, prevents overpressure by rerouting excess oil back to the pan. Visualize "Pump → Filter → Galleries → Relief → Pan" as a flow chart for quick recall.

  4. Filtration and Contaminant Control -

    High-efficiency full-flow and bypass oil filters trap particulates down to 20 microns, protecting wear surfaces in the gas engine cooling lubrication circuit. Some systems even employ magnetic or centrifugal filters per research from the SAE International Journal to capture fine ferrous debris. Remember that "Clean oil runs green" to link filter performance to engine longevity.

  5. Maintenance Intervals and Oil Analysis -

    Regular oil change intervals (often every 5,000 - 7,500 miles for modern gas engines) keep the lubrication system functioning optimally by replacing degraded oil and removing sludge. Oil analysis techniques, such as ASTM D6595 infrared spectroscopy and ISO 4406 particle counting, provide data-driven insight into wear metal levels and contamination. Track three key parameters - viscosity, total acid number (TAN), and wear metal concentration - to predict maintenance needs and extend engine life.
