Take the Engineering Welding Knowledge Test

Challenge Your Welding Techniques and Safety Standards

Difficulty: Moderate
Questions: 20
Learning OutcomesStudy Material
Colorful paper art depicting a welding helmet, tools, and quiz elements for Engineering Welding Knowledge Test.

Ready to boost your welding credentials? This Engineering Welding Knowledge Test is a practical welding quiz that evaluates core welding techniques and safety standards. Perfect for students and professionals wanting actionable feedback, it uncovers areas for improvement. Dive deeper with the Metallurgy and Welding Knowledge Test or try the Welding & Codes and Standards Knowledge Test. All quizzes are fully editable, so you can customize them in our quizzes editor.

What is the primary purpose of a welding helmet?
To clamp the workpiece securely
To protect the eyes and face from ultraviolet and infrared radiation
To hold the welding electrode in place
To measure welding current
A welding helmet shields the welder's eyes and face from harmful ultraviolet and infrared light produced by the arc. Without this protection, a welder risks severe eye injury and skin burns.
Which welding process uses a non-consumable tungsten electrode?
Oxy-Acetylene Welding
TIG Welding (GTAW)
Stick Welding (SMAW)
MIG Welding
TIG welding, or Gas Tungsten Arc Welding (GTAW), uses a non-consumable tungsten electrode to create the arc. Filler metal may be added separately, but the tungsten electrode itself is not consumed.
Which personal protective equipment is essential for protecting hands during welding?
Hard hat
Welding gloves
Ear plugs
Safety goggles
Welding gloves are made of heat-resistant materials like leather to protect hands from sparks, spatter, and heat. They are critical to preventing burns and injuries during welding.
What welding defect appears as a raised ridge of metal overlapping the weld toe?
Slag inclusion
Overlap
Undercut
Porosity
Overlap occurs when weld metal flows over the base metal without fusing properly, creating a raised ridge along the weld toe. This defect can reduce joint strength and should be avoided.
Which shielding gas is commonly used in MIG welding of carbon steel to achieve deep penetration?
Carbon dioxide
Nitrogen
Oxygen
Helium
Carbon dioxide is often used as a shielding gas in MIG welding of carbon steel because it provides deep penetration and a stable arc. It is cost-effective and widely available.
Which weld defect is characterized by incomplete fusion between the weld metal and the base metal?
Slag inclusion
Porosity
Cracking
Lack of fusion
Lack of fusion occurs when the weld metal does not properly fuse with the base metal or preceding weld bead. This defect weakens the joint and can lead to failure under load.
At approximately what preheat temperature should medium carbon steel be maintained to reduce the risk of cracking?
120°C
50°C
400°C
200°C
Preheating medium carbon steel to around 200°C reduces the cooling rate and minimizes residual stresses that can cause cracking. Proper preheat also helps hydrogen diffuse out of the weld area.
In welding symbols, which feature indicates that the weld must be made in the field (on site)?
Flag at the junction of the arrow and reference line
Filled arrowhead
Tail with specification
Circle at the arrow
A small flag placed at the junction of the arrow line and reference line in a welding symbol indicates a field weld, meaning it must be performed on the job site rather than in the shop.
What is the recommended arc voltage range for Shielded Metal Arc Welding (SMAW) using a 3/32" (2.4 mm) electrode?
30 - 35 V
20 - 25 V
40 - 45 V
10 - 15 V
Using a 3/32" electrode in SMAW, the recommended arc voltage is typically between 20 and 25 volts. This range provides a stable arc and sufficient penetration for good weld quality.
Which welding process is most suitable for joining thin aluminum sheets without burn-through?
Oxy-Acetylene Welding
Stick Welding (SMAW)
Flux-Core Arc Welding (FCAW)
TIG Welding (GTAW)
TIG welding offers precise heat control and low heat input, making it ideal for welding thin aluminum sheets without causing burn-through or warping.
What common cause leads to excessive spatter in an arc welding process?
Too high current
Excessive travel speed
Excessive shielding gas flow
Too low current
Excessively high welding current causes the electrode tip to overheat and eject molten droplets, resulting in increased spatter. Proper current settings help minimize this effect.
Which material generally does not require preheating before welding due to its low carbon content?
Stainless steel
High carbon steel
Low carbon steel
Cast iron
Low carbon steel typically has good weldability and low risk of cracking, so preheating is often not required. Higher carbon or alloyed steels usually need preheat to reduce cracking.
How is a double fillet weld indicated on a welding symbol?
A single symbol with a dashed line
Two fillet symbols, one above and one below the reference line
A circle around the reference line
A flag at each end of the reference line
A double fillet weld is shown by placing the fillet weld symbol on both the arrow side and the opposite side of the reference line. This indicates welds on both sides of the joint.
What is the effect of an excessively fast travel speed when welding?
Underfill and lack of fusion
Increased slag inclusion
Overfill of the weld bead
Excessive penetration
A travel speed that is too fast can result in underfill and incomplete fusion because there is not enough heat input or time to properly melt the base and filler metals.
Which fume is primarily produced when welding galvanized steel?
Iron oxide
Manganese oxide
Zinc oxide
Lead oxide
When welding galvanized steel, the zinc coating vaporizes and forms zinc oxide fume. Inhalation of zinc oxide can cause metal fume fever, so proper ventilation is essential.
On a welding symbol, what does a circle at the intersection of the arrow and reference line indicate?
Field weld
All-around weld
Contour finish required
Staggered intermittent weld
A circle drawn at the junction of the arrow and reference line signifies an all-around weld, meaning the weld is to be made continuously around the joint. This ensures full circumferential coverage.
For welding a 20 mm thick A36 carbon steel plate, which preheat temperature range is most appropriate to minimize cracking?
200 - 250°C
50 - 100°C
100 - 150°C
Room temperature only
For a 20 mm thick A36 carbon steel plate, a preheat range of 100 - 150°C helps reduce thermal gradients and hydrogen entrapment, lowering the risk of cracking.
Calculate the heat input (kJ/mm) for a welding process using 25 V, 200 A, travel speed of 300 mm/min, and an efficiency of 80%.
1.6 kJ/mm
1.2 kJ/mm
0.8 kJ/mm
0.5 kJ/mm
Heat input = (Volts à - Amps à - 60) ÷ (Travel speed) à - Efficiency ÷ 1000 = (25à - 200à - 60)/(300)à - 0.8÷1000 = 0.8 kJ/mm. This parameter helps control weld cooling rate.
Which non-destructive testing method is most effective for detecting subsurface cracks in a weld?
Magnetic particle testing
Ultrasonic testing
Liquid penetrant testing
Visual inspection
Ultrasonic testing uses high-frequency sound waves to detect discontinuities within the weld. It is highly effective for identifying subsurface cracks and inclusions.
During GTAW of chromium stainless steel, which shielding gas composition is optimal for arc stability and weld quality?
Pure helium
50% argon / 50% helium
Pure argon
75% argon / 25% carbon dioxide
Pure argon is the most commonly used shielding gas for GTAW of stainless steels because it provides a stable arc and good weld bead appearance without contamination.
0
{"name":"What is the primary purpose of a welding helmet?", "url":"https://www.quiz-maker.com/QPREVIEW","txt":"What is the primary purpose of a welding helmet?, Which welding process uses a non-consumable tungsten electrode?, Which personal protective equipment is essential for protecting hands during welding?","img":"https://www.quiz-maker.com/3012/images/ogquiz.png"}

Learning Outcomes

  1. Identify essential welding processes and equipment.
  2. Analyse weld quality and detect common defects.
  3. Apply correct safety procedures in welding operations.
  4. Evaluate material selection and preheat requirements.
  5. Demonstrate understanding of welding symbols and standards.
  6. Master proper parameter settings for various welding methods.

Cheat Sheet

  1. Understand the four primary welding processes - Dive into SMAW, GMAW, FCAW, and GTAW to see how each method brings its own spark to the table. By knowing their unique gear and ideal uses, you'll pick the perfect match for any welding adventure. Feel empowered to choose wisely and weld like a pro! Understanding the Differences Between Arc Welding Processes
    2. Understanding the Differences Between Arc Welding Processes
  2. Identify common welding defects - Spot porosity, cracks, and undercuts before they crash your weld party. Learning to recognize these troublemakers keeps your joints strong and safe. Practice those visual checks and become a defect-detecting detective! Common Welding Defects
    3. Common Welding Defects
  3. Master welding symbols and standards - Crack the code of weld symbols to understand exactly where and how to weld. These tiny icons carry big instructions on weld size, type, and finish. Level up your blueprint reading and weld without second-guessing! Welding Symbols
    4. Welding Symbols
  4. Prioritize material selection and preheat - Choosing the right metal and preheating it correctly can stop cracks and hydrogen headaches in their tracks. Preheat empowers cleaner, stronger welds by keeping temperatures steady. Always check specs and give your metal the warm-up it deserves! Preheating: Why, When and How
    5. Preheating: Why, When and How
  5. Learn welding codes and standards - AWS, ISO, and more spell out the rules for safe, high-quality welds. Staying current with these guidelines keeps your work consistent and code-compliant. It's like having a rulebook that leads straight to professional excellence! List of Welding Codes
    6. List of Welding Codes
  6. Set proper welding parameters - Voltage, current, and travel speed are your welding holy trio. Tweak these settings to match each process and metal type for rock-solid, defect-free joints. Experiment, record results, and watch your weld quality shoot through the roof! Understanding Welding Parameters to Achieve Better Welds
    7. Understanding Welding Parameters to Achieve Better Welds
  7. Tackle hydrogen embrittlement - Keep moisture and hydrogen out of your weld zone to prevent brittle failures. Proper electrode storage and dry handling techniques are your best defense. Stay vigilant - your welds will thank you with lasting strength! Hydrogen Embrittlement
    8. Hydrogen Embrittlement
  8. Explore post-weld heat treatment (PWHT) - PWHT swoops in to relieve stress and refine your weld's microstructure. Choosing the right heat cycle boosts toughness and durability for critical builds. Embrace this finishing touch to elevate your welded creations! Post Weld Heat Treatment
    9. Post Weld Heat Treatment
  9. Practice non-destructive testing (NDT) - Ultrasonic and radiographic tests let you peek inside welds without scarring them. These high-tech inspections catch hidden flaws early, ensuring your structures are rock-solid. Get hands-on and build confidence with every scan! Non-Destructive Testing (NDT)
    10. Non-Destructive Testing (NDT)
  10. Champion PPE and safe practices - Welding without the right gear is like skydiving without a parachute - never a good idea. Helmets, gloves, and flame-resistant clothing keep you injury-free and ready to weld another day. Safety first, sparks later! Welding, Cutting, and Brazing
    11. Welding, Cutting, and Brazing
